This 26 gallon still has it all! Comes with 3" copper and stainless reflux column, (2) 2" element ports, for heating element adapters (adapters sold separately) tri clamp gasket and cover plate. This boiler can also be fired with a propane burner. The bottom of the boiler is flat and recessed.

Comes with:

• 3" Tri Clamp with 3" Silicone Gasket for connecting the column to a still.
• Commercial 3" face thermometer.
• 3" Tri Clamp dephlegmator connection with 3" Tri Clamp and 3" Silicone Gasket.
• Built in stainless Liebig condenser.
• 1/2" hose barb connections on the condenser and dephlegmator (pre-condenser) for cooling water.
• Dephlegmator (pre-condenser) for increasing and controlling proof.
• 1.5" drain valve with down spout.
• Carrying handles
• 2" filler port with tri clamp, gasket and cap
• 4" column connection
• Top quality construction, with beautifully rounded curves
• Built from heavy gauge 304 food grade Stainless Steel
• Polished to a mirror finish inside and out

Base Diameter: 19 3/4"

This Controller works great for 20 to 35 gallon stills and still boilers as well as our beer keg stills up to 15.5 gallons (must have 2 element ports). You will need to attach your own 60 amp 220 VAC dryer or welding plug to the main power cord so that you can plug the controller in. If you are going to use this heating element controller with your own boiler your boiler will need two 2" tri clamp ferrules, two 2" tri clamps and two 2" tri clamp gaskets. This controller draws 50 amps @ 11,000 watts 220 VAC Single Phase.

This controller includes:

• (2) Ultra Low Watt Density Heating Element
• (1) Variable Temperature Control
• (2) 30 Amp Twist Lock Male Plugs
• (2) 30 Amp Twist Lock Female Plugs
• (2) Industrial Power Switches
• (1) 40 Amp SSR
• (2) 30 Amp 2 Pole Breakers
• (1) 30 Amp Panel Meter
• (2) 12' cords from the Controller to the Element Boxes
• (1) Lidded enclosure
• (2) Green Power On Lights

The cooling kit for our 2" & 3" Stainless Reflux Columns. Use the blue hose for your cold water line, and the clear hose for your hot water line. These cooling kits will work for hose barb connections that are 1/2" ID.

The tubing you will receive could be orange, blue or clear.

Parts List:

• 12 feet of 3/8" Tubing (6 feet of clear tubing, 6 feet of blue tubing)
• 12 inches of 1/2" Clear Tubing
• (2) 3/8" Push to Connect Flow Tees
• (1) 3/8" Push to Connect Union Y
• (1) 3/8" Push to Connect Union Tee
• (2) 3/8" Male Straight Pipe Fittings
